Swapping a lightweight image for an animated SVG

I’ve been on a mission to improve performance since I migrated this site to Eleventy, especially after I realised I was burning through bandwidth once I moved to Netlify. Some of the biggest offenders were the animated illustrations I use across the site. They look great, but they ain’t cheap.

A typical animated banner contains an inline SVG, CSS, and JavaScript. By the time everything is in place, the animation can easily weigh half a megabyte. Because the SVG needs to be inline, all of that markup becomes part of the initial HTML document, increasing the amount of work the browser has to do before it can paint the page, and making every visitor download an animation whether they’ll see it or not.

My solution was to load a lightweight static AVIF image first, then replace it with the animated SVG only when the conditions are right. Everyone gets an immediate visual. Larger screens get the richer animated experience once the page has settled. Smaller screens never know the animation exists.

Start with a lightweight fallback

I began with a picture element inside the banner:

<div id="animation-banner">;
<picture>
<source
srcset="static-placeholder.avif"
media="(width >= 64em)">
  <img src="static-scene-small.avif" alt="">
</picture>
</div>

The browser chooses the appropriate image for the viewport, so there’s no JavaScript involved in the initial render and no opportunity for layout shifts.

Next, I added two data- attributes. One points to the HTML fragment containing the animated SVG. The other tells the script which media query should trigger the enhancement:

<picture
data-animation-src="/fragments/scene.html"
data-animation-media="(min-width: 64em)">
…
</picture>

That leaves the HTML completely declarative. The page works perfectly well without JavaScript, while the animation becomes an optional enhancement rather than a requirement.

Waiting until after first paint

The script begins by finding the banner and reading those attributes:

const picture = banner?.querySelector("picture[data-animation-src]");
if (!banner || !picture) {
return;
}
const fragmentUrl = picture.dataset.animationSrc;
const mediaQuery = window.matchMedia(
picture.dataset.animationMedia || "(min-width: 64em)"
);
const originalPicture = picture.cloneNode(true);

I deliberately avoid replacing anything immediately. Instead, I wait until after the browser has completed its first paint by nesting two requestAnimationFrame() calls:

window.requestAnimationFrame(() => {
window.requestAnimationFrame(() => {
syncBanner();
});
});
}

The double requestAnimationFrame() gives the browser a chance to render the placeholder image before any fetching or DOM replacement begins.

That means visitors see useful content almost immediately instead of staring at a blank banner while the animation downloads.

Fetching the animated SVG only when needed

If the viewport matches the media query, the script fetches the HTML fragment containing the animation:

if (!fragmentUrl) {
return "";
}
const response = await window.fetch(fragmentUrl);
if (!response.ok) {
throw new Error(`Failed to load ${fragmentUrl}`);
}
return await response.text();
}

This is where most of the savings come from. The animation isn’t part of the original HTML, so it isn’t parsed during the initial page load and isn’t downloaded on mobile. Only browsers which can actually display the richer experience pay the extra cost.

Keeping the animation inside its own HTML fragment also makes the page templates much easier to manage. The SVG, its embedded styles, and the JavaScript needed to drive the animation all live together instead of cluttering the page template itself.

Parse and replace the banner

Once the fragment has been downloaded, I parse it with DOMParser and replace the original contents of the banner:

const doc = new DOMParser().parseFromString(fragmentHtml, "text/html");
const nextBanner = doc.querySelector("#animation-banner");
const fragmentContent = document.createDocumentFragment();
Array.from(nextBanner.childNodes).forEach((node) => {
fragmentContent.append(node.cloneNode(true));
});
banner.replaceChildren();
banner.append(fragmentContent);
}

Using a DocumentFragment means the browser only updates the live DOM once, rather than repeatedly as individual nodes are inserted. It’s a small optimisation, but it keeps the replacement nice and tidy. The swap itself is almost invisible. People briefly see the static illustration before the animation quietly takes over.

Restoring the static image

One thing I didn’t want was to assume the viewport would never change. If someone narrows their browser below 64em, the animated SVG disappears, and the original lightweight image comes back:

banner.replaceChildren(originalPicture.cloneNode(true));
}

The synchronisation function simply keeps everything in step with the current media query:

if (mediaQuery.matches) {
const fragmentHtml = await fetchFragmentHtml();
if (fragmentHtml) {
renderAnimation(fragmentHtml);
}
return;
}
restorePicture();
}

The enhancement becomes reversible instead of being a one-way upgrade.

Why I like this pattern

There are other ways to tackle this problem. I could have left the SVG inline and accepted the extra HTML. I could have hidden it with CSS on smaller screens. I could even have embedded the animation in an object or iframe. None of those approaches really solved the problem I was trying to fix.

So far, this approach feels like a good compromise. The page paints quickly, the animations are still there when they add something, and I’m no longer asking every visitor to download half a megabyte of SVG before they’ve even seen the page.

I’m sure I’ll keep tweaking it. I usually do. But for now, it feels like a sensible balance between performance and personality.
